Wood Working Panel Saw Machine Details

The Wood Working Panel Saw Machine from Aarati Industries is specially designed to deliver precise and efficient cutting of various wood panels such as plywood, MDF, particleboard, and laminates. Combining sturdy construction with smooth operation, this machine is ideal for woodworking shops and manufacturers looking for accuracy and reliability in their panel cutting processes.

With its user-friendly design and adjustable settings, the Wood Working Panel Saw Machine ensures consistent performance, helping you achieve clean cuts and superior finish quality every time.

Digital display for the saw Blade angle tilting.
Manual control main saw and scoring saw angle tilt.
Electric control main saw up and down.
Dimension of sliding table : 3200×375mm
Width of cut between saw blade and rip fence : 1250mm
Diameter of main saw blade : 300 mm
Main spindle diameter : 30mm
Speed of main saw spindle : 4000/5000/6000 rpm
Diameter of scoring saw blade :120 mm
Scoring saw spindle diameter : 20mm
Speed of scoring saw spindle :8000 rpm
Tilting saw group : 0°-45°
Max cutting height (90°) : 80 mm
Max cutting height (45°) : 55mm
Main saw motor power : 7.5hp
Scoring saw motor power : 1.5hp
Voltage : 220v 50Hz (optional)
Weight : 800kg
Dimension : 3250×3390×830mm
