Plywood Laminate Hydraulic Cold Pressing Machine
Plywood Laminate Hydraulic Cold Pressing Machine Details
The Plywood Laminate Hydraulic Cold Pressing Machine by Aarati Industries is expertly designed for applying laminates and veneers to plywood and other panel materials using hydraulic pressure—without the use of heat. This machine provides uniform, powerful pressing force to ensure flawless bonding and a smooth finish, preserving the quality of heat-sensitive laminates and wood veneers.
Built with heavy-duty construction and advanced hydraulic systems, it is ideal for plywood manufacturers, furniture makers, and laminate processors who demand precision and durability.
Maximum load on work piece. 170Ton
Platen size 3150x1300x16mm
Maximum opening. 1000mm
Number of hyd cylinder. 6nos
Cylinder diameter. 125x90
Hydraulic power pack. 7.5 HP
Hydraulic pump capacity. 40 liter
Oil tank. Capacity. 180liter
Weight of machine. 4200 to 4500 kg
